Minutes of Meeting with M/s. Rashmi for PR NO BPM006460 - AJA/GPP-3&4/PR/127/2024 - Supply of MCC Panel

• Power Terminals shall be inside the feeder for Each Motor,
• Each Starter will be with space Heater power ON/OFF Circuit as Location of the Motors are near Sea-Shore,
• Considering Heavy duty VFD with ABB - ACS 880 / Amtech -Axpert Easy plus,
• Consider Heavy duty  Soft starter With ABB –PSTX / Amtech – Axpert Opti,
• VFD technical data sheet will be provide,
• We will submit the OEM recommendation for Input/Output Line Chokes (Cable distance :500mtrs), Fan-Filter & Feeder size for proper heat dissipation.
• We will submit the OEM recommendation for Fan-Filter & Feeder size for proper heat dissipation.
• Excel or equivalent make of Use of Electronic Type Relay instead of Thermal Overload,
• Panel above 6mtr shall be Double Front,
• DCS Chamber shall be in Front for Front-Feeder & in Rear for Rear-Feeders,
• Cable Alley should be also spacious,
• Color of the wire & terminals shall be of different color for DCS,
• Terminals shall be shrouded Type for DCS,
• All Vacant feeders shall be considered as 125A MCCB Outgoing Power Feeders.
•
